Fitting lapstrake (clinker) planks can be one of the trickiest parts of traditional boatbuilding—but when done right, it results in a beautiful, strong hull. In this episode of Building Gannet, I walk you through essential tips and techniques to get your lapstrake planks to lay down in their natural position using glued epoxy construction.
From clamping strategies using buttons, cam clamps, and clinker pins, to diagnosing fit issues like flaring and gaps, you'll learn how to adjust your gains, bevels, and patterns for a tight, fair fit. I also share how to handle back beveling at the bow, deal with flare, and use thickened epoxy for a forgiving but strong bond.
Whether you're a beginner or an experienced wooden boatbuilder, this series provides in-depth guidance with practical shop tips for fitting and hanging planks with confidence.
👉 Chapters: 00:00 Intro 00:41 Using Clamps & Buttons 02:00 Diagnosing Gaps & Misalignment 06:19 Adjusting Gains & Bevels 11:29 Back Beveling for Bow Flare 14:54 Final Fit at the bow 17:52 Transom Gain 22:10 Getting the fit just right 24:51 Creating a hard registration point 25:52 Wrapping Up
📌 Want to see how we cut gains or pattern planks? Check out previous episodes in the Building Gannet series!
🧰 Support this channel: 👍 Like, 💬 Comment, 🔔 Subscribe 💙 Become a Patron 💸 Use Super Thanks to support future builds
Thanks for watching and stay tuned for the next episode, where we’ll glue and fasten this plank into place!
The trick to lap strike planking is getting the plank to lay down in its natural shape and that
means as it touches onto the molds and the planking above it there's one position in which it wants to
lay down. Now fitting planks can be a little bit tricky at times but there are a few fundamental
ideas that you need to keep in mind when trying to fit lap strike planks and I'm going to share
those with you today. Howdy folks I'm Mark Cruden welcome back to Nomad Boatbuilding.
We have been learning about the glued lap strike planking process using our current project
Gannet. In our first few episodes we dealt with beveling laps, we dealt with cutting gains and
our last episode we patterned and made a plank. Today we're going to hang that plank and get it
fitted. So when we're lap strike planking there's quite a few moments in the process where we need
to clamp our planks in place often in the exact same place that we had them a few moments before.
Now there's a bunch of clamps that we use for fastening planks at the laps.
There's F-body clamps, deep C clamps, there's cam clamps, Brenner clamps and clinker pins.
These are all great clamps for clamping at the laps. Now I use a button just something like this
and the purpose of this particular style of button is that I can fasten this to a stem
or a mold and that it catches the plank here in the notch.
It's only occurred to me in this last plank to
take my buttons and just screw them to the mold so that they're here when I need them.
I don't need these at every mold that's for sure but certainly helps to sort of tack it in place
quickly. I'll tell you though these are a huge time saver over fumbling around with clamps to
tack things in place. Okay, let's get the plank on here. There we are. Okay, pop that on.
Looks like I'm sitting... I'm sitting a hair low in the middle I am. We'll adjust that in a moment.
So with these planks the gain is what really kind of locates the plank mostly.
At least up at the bow end that's what locates it. The trick to lap strake planking is getting
the plank to lay down in its natural shape and that means as it touches onto the molds
and the planking above it there's one position in which it wants to lay down
and sometimes the plank you cut doesn't specifically fit that. So right now you'll
see I've got sort of a large gap here that shouldn't be there. Now I know I spiled to
my lines properly. It could be that my pattern wasn't stiff enough and it kind of imparted a
more of a sweep down that gave me this final plank shape that isn't quite jiving.
So I have to figure out how to address this. Even under the best of circumstances things can
not quite fit no matter how good a job you did at patterning for those planks.
But there are a few fundamental ideas that you need to keep in mind when trying to fit lap
strake planks. If you keep these ideas in mind they should guide your hands and get you a pretty
good fit. Remember we're using epoxy construction here so that gives us a lot of wiggle room. Even
if you don't get it 100% right that's fine. That thickened adhesive will fill in any gaps
and make for a solid waterproof seaworthy boat. Mostly what this is telling me is that this
plank has to move up but not here at the end. So if I push that up here now it fits nicely
but it's flaring right there. Now maybe it's just a question of
it wants to twist but that's kind of forcing the plank. I'd like it to sort of lie down
naturally. So I'll play around with like bringing it up in the middle just a hair and see if I can
get it to fit better. Sometimes it's like even a sixteenth coming up in the middle might adjust
this end down so that it can lay down properly. So I'm just going to play around with that kind
of thing for a while. Now if it were landing high I might have the opposite problem on hand.
But come down part way so that this is crossing here it feels like it's going to fit nicely but
I got to adjust either the top of this plank here give it more sweep or I need to adjust
the gain here cut it cut it back a little bit so that it opens up. So the goal is to try and
do the minimum amount of manipulation and shaping to get this to fit. So play around a bit
and of course we want to make sure the other side mimics this side for symmetry's sake.
Looks like to get this to fit well if I look at how it's landing further forward and rolling down
I think I need to adjust the gain here a little bit it's bring it down low so it hangs in the
gain the whole plank's got to come down a fair bit in order to fit in there. I don't think that's
what it wants to do it wants to sit a little higher. When you have a situation like this where
you put the plank down into the gain you got a gap there it could be the whole plank needs to
shift down in midships but if it's flaring out here like right now if I push that down I try and
get it into that spot it's popping out like flaring out here that tells me that this wants
to be lower so if I let that lower down a little bit then this suddenly flattens out up here so
it tells me the whole thing might need to shift up a little and I need to adjust either the top
of this plank in here so it fits into this gain or I need to adjust the gain itself to fit the plank.
Okay I think all things considered I'm better off taking the top of this down a little bit
well it's probably easier to just do the gain. If I look at my molds I'm touching right at my
lines on the bottom side so position's about right just the shape's just falling a little bit wrong
if you if we do what I just did scribe along the planking you'll see it's actually a really
small margin the gain like stops even having any depth of thickness right about there like there's
no depth so it's just a small area in which I need a little less meat it's just a strong 16th
in through here that is preventing the plank from sitting in there nicely.
Now maybe I can just use my plane and nibble it out.
The danger in doing this is you slip and you send your plane scratching across that surface and
chewing it all up of course and that's where it gets really thin that it becomes really hard to
do nicely.
Might help to score a line with the knife.
Yeah I can see it starting to fit better already.
if you're liking these videos you can support me by giving me a thumbs up,
throwing me a couple of bucks with super thanks, subscribing to the channel, turning on notifications
and of course you can join me over on Patreon. Find links in the corner or down in the description.
Yeah it's looking better already.
Sometimes these margins are really small it's like just like right here
there's almost no ledge and yet it's holding up the plank.
Holding up the plank from being where it wants to be
and there's just it's a it's a really difficult spot to try and
get the plank to lay down nicely. Now I know I need to do a bit of back beveling so
I should check check on that right now.
So I get that sort of up where it needs to go and now I'll just get a mirror and have a look inside
see if I can get a sense of how much work it needs.
Now this specific boat design features some flare in the bow.
It's not something that we encounter very much in lapstery construction
and so what that means is near the bow our plank laps have to react a little bit differently.
We can't bevel them off as we normally would because the plank that lands on the outside
is kicking outwards. That means we actually have to bevel the outside plank instead of
the inside plank for a portion of that plank length. Now that sounds tricky it's not so bad.
Basically what that means is the bevel that you've been cutting along the hull
will just feather out and stop existing. It'll just be a flat face of the plank and then the
new plank that goes on there has to start getting beveled from that flat face towards the stem.
So to get this plank fitting properly because it basically has to kick out a little bit
I need to back bevel it. So I've got this small plane that I use for doing that.
It's got a very slight crown to the blade and a slight crown to the sole and I've got a line
carved into the sole here for reference. It sort of marks the middle of it and so I use that to
help orient the plane. So I know I need about a three-quarter inch bevel on here and that's
normally the width of the plane blade from the center out inch and a half blade. So what I'll do
is I'll try and bend the plank a little bit make it convex on the inside and then figure out the
spot that I want to start this bevel and then I'll just carefully run that plane along there
tapering it off to where I need it to stop back beveling.
And when I get to the proper depth this little shaving should be about three-quarters of an
inch wide so it's going to take a few strokes to get there.
Of course I've got the veneers that I can look at to judge.
Of course this needs to be tapered as well towards the ends of the cut so it's deepest
in the middle in the center of this little section where I need it to be back beveled
which is deepest right about here. So right now I'm just about through the surface
veneer just at the top edge and I can see it's tapered off towards the bottom to about
three-quarters of an inch take another couple strokes. I can tell just by sound I've made it
through that surface veneer so you can see the veneer showing here so that's the back beveling.
So we'll swing the plank into place and have a look at it now. If this idea of back beveling
totally freaks you out don't worry you could just omit it altogether because we're using
thickened epoxy in our joints we can just make sure we use some extra epoxy in those areas to
fill that joint. It'll be just fine.
So that's starting to fit my rabbet reasonably well.
Still a hair tight near the top. Give it a couple of strokes.
Looks tight near the top now. It's hard to judge without clamping it in place.
Just some light clamping just to mimic fastened pressure.
I'm going to swing this in. Let me get in here with my mirror and have a look on the inside.
It's looking pretty good. That's reasonably tight and of course it's epoxy construction
so I don't need to get it 100%. 90-95% will be fine because the epoxy will fill.
Of course if I'm doing this with traditional construction I got to make it 100% so
that takes a little more time and effort and attention to detail.
For the most part this feels like it's all coming together nicely.
I think I might put a couple more strokes.
Hopefully get this line looking a little more even.
Again this doesn't have to be completely invisible because epoxy will fill it as well.
That's feeling like it's pretty good. I got a little work to do on the
stem face to get this to fit in properly but for the most part it's all looking great.
Yeah I can see it wants to rock here which means I've got a bit of a crown
in here that I need to tease out. I just can't cup 3-eighths plywood like this. It's too stiff.
When I come along back here and I apply some light finger pressure does the joint close up
and if so great and if it doesn't I might need to do a little bit of work. For the most part
it's looking good. I've got to cut my gain at the transom still but I'm liking where this is going
so I'll turn my attention to finishing up the stem face here to get this fitting nicely and
then I'll go back and I'll take care of the transom. You know it's funny if I just push
straight down you see that drops but if I push down from the bottom that causes it to twist
it comes up and rises up to where it needs to be so there's a fair bit of flare in this so
that's that's what's affecting this and after the use this plank is on then I can attend to
beveling off this in whale in order to fit properly as well because that's got to get
beveled off to match this plank in there to meet where the lap line lands on this planking.
I'm prepping to do my gain here I run the bevel of this on this plank to just sort of match the
same angle as the transom so I don't try and bring it all the way down I just I take this station
angle and it's probably pretty close to this one and I can just kind of carry that straight through
until I hit my lap line and I call it good I don't worry about how deep it is so this plank
right now is just sitting down on the transom haunch I pop it out and see what we've got here
so with it sitting there and it feels like the plank it could go a little lower here just a hair
by the way it's springing a few strokes off of that that allows it to sit down just a little
bit tighter now that that sits down tighter it's not forcing this plank back here to bow out because
if this comes up higher I'll just show you as I swing this up you'll see how this flares out
now if I push it down lower it flares out back there so we want to find that spot
it's solid against our mold here solid here so now we know we're in the right position for the
plank back here actually one of the reasons I leave my planks hanging over the transom like
this I've got myself about an inch of extra space so I can do stuff like this I can just
clamp this on right here and that's just right for holding it in place I'll trim all of these
off at the end start with a few scoring cuts and so I just want to set this up so it's covering my
my kerf the same thing down here now I'm not worrying about this end touching my line I'm
worried about it covering off the length of the kerf because it because the shape of the plank
this might not be a straight line all the way back to there so it's really this this area here I'm
concerned about final check before I start planning that I've got my line covered off
looks good and now starting out real gentle I pick up this angle right here on the transom
I keep checking my angle
extend my strokes short to long or long to short either way you go
doesn't matter which
check my angle now I want to be really careful that as I'm planning this portion I don't go
flying off the end of the transom and break out the material along this edge that's really easy to do
what I'll sometimes do is I'll get real close and then I'll come back the other way and
playing against the grain just to avoid doing that
might even be wise to finish up with a sanding stick
carefully take a few strokes check your work take a couple of strokes check your work
you might have to take a little lick off this inside corner here if it's
still not sitting down it could be there's just something that's hanging up there
so yeah I've got a little tiny crown to the transom here that's one of the things holding me up
better there we go that's nice and tight now yeah you notice a little bit of a bounce here
there's really not much I can do about that it's because there's because there's like
bow being imparted here
you pretty much have to take this gain all the way back to try and get rid of stuff like that
generally it all works itself out you might end up with a little bit more flare here than
the lines intended to that helped it a little bit just that few strokes right there
not the end of the world so this is ready to go get glued on softened the outboard
edge of this so that it's not too sharp we don't touch this one where the lap is going to go and I
soften the inboard edge down here that's going to be exposed in the finished boat just so that I
don't have big splinters I can get caught on sandpaper and stuff later on when I start cleaning
up the inside now when we're rehanging a plank especially when we're going to glue it we want
to make sure that our plank is located in the exact same position that it was as we're doing
our fitting and so for this reason I'm just using a single finishing nail tucked through these
planks so that when I come in here with a glued up plank I can drop it down and just get that
finishing nail locating us fore and aft and that takes care of everything we need in order to get
this into its finished position the hood ends at both ends are going to locate both ends of the
plank to their finished position and so this just helps me to get in the right spot in the first
place so that those all work out now of course you can put some registration marks right on the
plank and on the plank below it that's a good idea too having a physical registration mark
like this ensures that it's getting located both vertically and horizontally into the spot that it
needs to go into as long as you're taking the time to make sure that we're sort of touching
at the molds properly and that the planks aren't trying to flare off the mold in any awkward way
a little bit of clamping pressure to bring it down into a good fit doesn't hurt we don't want
to be wrestling those planks into a good fit because that's going to affect sort of how it all
kind of works together that is to say the less wrestling you do the better off you are if you
have to do a lot of wrestling maybe you should take a look at how your planks are fitting again
and see if you can't sweeten those up the nice thing about lap strike planking is that we don't
100% have to hit our marks if that plank has to sit a little bit high on our marks in order to fit
at the balance during properly that's okay we can make the next plank just a little bit wider to
compensate if it has to sit a little bit low that's okay too the most important aspect i think
is that the plank lies in as neutral a state as possible such that you're not having to try and
wrestle those edges into position so now that the plank is fitted we can move ahead with fastening
that plank in place but we're going to save that for the next episode of building gannet and i hope
you join me for that one i want to thank all my followers who support these videos over on patreon
and if you can support me there too i would really appreciate that you can find links in the corner
or down in the description and i want to thank everybody else here on youtube for liking
subscribing and all that sort of stuff so i hope you join me again next time i'm building gannet
until then keep your stick on the ice
