now we will see the harmonic vibrations
of dam systems so in free vibrations we
have already seen damped free vibration
and damping is the property by which the
free vibration of a system diminishes
with time and damping is because of many
energy dissipation mechanisms present in
the system so now let's look at a
viscous lead and system so in viscously
damped system the damping is represented
by a viscous damper and the damping
force will be equal to the damping
coefficient multiplied by the velocity
of this mass so the equation of motion
of this type of systems we have written
for free vibrations and in forced
vibration when a harmonic force of P
knot sine Omega G is acting on the
system the equation of motion becomes
this it is MX double dot plus CX dot
plus KX is equal to the harmonic force P
knot sine Omega T and the system will
have some initial displacement and
velocity and we assume that we know this
initial conditions we can rewrite this
equation of motion like this and we can
define this theta as a damping ratio
which is the damping coefficient divided
by the critical damping coefficient and
we have also seen in free vibrations
that the critical damping coefficient is
equal to 2 m Omega n or 2 root K M so
now we have this equation of motion and
we have to find the solution of it so
here also the solution will consist of
two parts the complementary solution and
the particular solution the
complementary solution will be equal to
the homogeneous solution that is the
solution to free vibrations so now we
will find the particular solution for
that we will assume that the particular
solution is of the form C sine Omega T
plus D cos Omega T so now we have to
find out these constants C and D so for
that we have to substitute this equation
in the equation of motion in this
equation of motion and then we have to
find out these constants let's
substitute this equation and its
derivatives in this equation of motion
so we have to find the velocity function
by differentiating this once so if you
differentiate this once you get C Omega
cos Omega t minus D Omega sine Omega T
that is the velocity of this particular
solution similarly we can find out the
acceleration by differentiating this
velocity once more so the acceleration
would be minus C Omega square sine Omega
t minus D Omega square cos Omega T now
we can substitute the particular
solution expressions for displacement
velocity and acceleration in this
equation of motion so if you do that
substitution we will get this expression
so first we have X double dot so the
first two terms will represent this
acceleration and 2 Zeta Omega n
multiplied by the expression for
velocity then Omega n square multiplied
by
the displacement terms so we have this
expression which is equal to P naught by
M sine Omega T which is the force so now
we can rearrange this equation so we can
collect all the sine Omega T terms so
sine Omega T multiplied by minus C Omega
square then this star to seat Omega L D
Omega then the next sine Omega T term is
this C Omega n square then we have the
cos Omega T terms so minus D Omega
square plus the star C 2 C 2 Omega L
Omega then we have this term which is
equal to Omega n square D so we just
rearrange these terms in sine and cosine
terms so now we can equate the sine and
cosine terms on both sides so these are
the sine terms on left hand side and the
right hand side we have 1 sine term sine
Omega T term so we can equate these
terms to this one we can also equate the
cos Omega T terms to 0 because in the
right hand side there are no cos Omega T
terms so if you do that we will get two
expressions one is this equal to P
naught by M the second is this
expression equal to 0 so we can
rearrange this again and we will get an
expression like this from this equation
and another expression from this
equation so you have to
equations and two unknowns C and B so we
can solve this algebraic equation and
find out the expressions for our
constants C and D so after solving these
two equations we will get the
expressions for C and D and that will be
equal to C is equal to B naught by K 1
minus frequency ratio square divided by
1 minus frequency ratio square the whole
square plus 2 Zeta frequency ratio
Square and D is equal to this
P naught by K the numerator will be
minus 2 Zeta frequency ratio the
denominator will be same as C now we
know the values of C and D so we can
write the expressions for the particular
solution as C sine Omega T plus D cos
Omega T and we know that the total
solution is the sum of complimentary
solution and the particular solution so
we have seen in harmonic vibrations of
n'dam systems that the complementary
solution would be equal to the free
vibration response so here we have the
total solution as the complementary
solution and the particular solution so
this is if you remember the free
vibration response of the damped system
which is equal to e to the power minus
Zeta Omega NT multiplied by a cos Omega
DT plus B sine Omega DT so this Omega D
is equal to the natural frequency of the
dam system which is equal to Omega n
which
the natural frequency of the undamped
system multiplied by 1 minus Zeta square
sita is the damping ratio so now we have
the total solution so if you look at the
solution these two terms they decay with
time so this exponential function this
in terms of T so as time increases this
these two terms decrease with time so
this part of the solution is known as
transient response because this decays
with time and this part is known as
steady-state response so this will not
decay with time this will be the
predominant response because this part
decays with time and this will be
remaining as long as the force remains
so this is the predominant part of the
response so as we have did earlier we
can calculate the constants a and B
using the initial conditions so we have
the initial displacement and initial
velocity so you can substitute the
initial velocity in this expression and
we can find out the velocity expression
by differentiating this ones and
substitute the initial velocity value in
that and then we will have two equations
if you solve those two equations we will
get the value of a and B so if you do
all that we will get a is equal to X
naught the initial displacement minus
this expression D and B will be equal to
this I am NOT showing this derivation in
this video but I would like you to try
this out and calculate these constants
so now let's see how the solution looks
like so if you plot
this total solution for some values of
initial conditions we will get the
solution like this the blue line
represents the total solution the red
dotted curve represents the steady-state
response so and if we plot only the
transient response it will look like
this so as expected this transient
response will decay in time and become
zero after some time and if you look at
the total solution initially the total
solution will vary like this it is the
sum of the steady-state response and
this transient response so after some
times as the transient response decays
the total solution will become equal to
the steady-state response and that's why
this part of the solution is known as
steady-state response because that part
of the solution remains as long as the
forces available now
let's look at the vibrations response at
Omega is equal to Omega n in undamped
systems we have seen that when the
forcing frequency is equal to the
natural frequency the response becomes
unbounded the amplitude of the steady
state response increased in each cycle
now let us see how the damped system
behaves when the forcing frequency is
equal to the natural frequency so we
have the expressions for the constants C
and D when Omega is equal to Omega n
this ratio will become 1 and C will be
equal to 0 this numerator will become 0
so here in the expression for D this
term will become
- - Sita and this term will vanish and
this term in the denominator will become
2 Zeta the whole square so together this
will become denote by K minus 2 minus 1
divided by 2 Zeta so C becomes 0 and D
becomes this value the complementary
solution can be found out using the
initial conditions for 0 initial
conditions the total response of this
damped system will be this and as you
can see these terms decay with time so
they represent the transient response
and the steady-state response is this
which is a function of Omega n as the
forcing function is equal to the natural
frequency now let's see the solution
graphically so the solution looks like
this the amplitude of this steady state
response is equal to P naught by K
multiplied by 1 by 2 Zeta unlike in the
case of under damped systems this
amplitude is not a function of T so this
is a constant and this does not increase
with time so that means in the steady
state response we have a bounded
response the amplitude of the steady
state response is equal to this value
and this does not change with time this
stays constant with time and as you can
see here in the beginning when the time
is small we have the effect of this
transient response so after some time
the transient response will decay and
will become equal to 0
after some time so the total response
converges to the steady-state response
and continues as long as the force
remains and the amplitude of the
steady-state response is also constant
so the amplitude does not increase with
time so now you would be able to
appreciate the effect of damping in
systems in undamped system we have seen
that at Omega is equal to Omega n the
response increases after each cycle so
as the time goes by the response keeps
on increasing but damping makes that
response bounded and it makes it bounded
to this value no matter how many how
much time passes the maximum amplitude
of the response will be this much denote
by K multiplied by 1 by 2 Zeta so if the
damping is high the amplitude will be
smaller and the damping is small the
amplitude will be larger and we know
that the P naught by K is equal to the
static response now let's explore the
steady-state response in detail as the
transient response decays with time the
steady-state response is the predominant
form of vibration so as we have seen
already this is the expression for the
steady-state response and this can be
alternatively expressed as X naught
multiplied by sine Omega t minus V so
this sine and cos terms can be written
as a sine term with some phase angle and
here the X naught is equal to the square
root of c square plus d square and the
phase angle this tan
- Deeb I see so we can calculate all the
expressions for C by D using that we can
calculate the amplitude it will be equal
to P naught by K multiplied by 1 by
square root of 1 minus frequency ratio
square the whole square plus 2 Sita
frequency ratio the whole square so we
have seen that this P naught by K is
equal to the static response and this is
a multiplication factor by which the
amplitude of this response amplifies or
decreases and the fee can be found out
as tan inverse 2 Zeta frequency ratio
divided by 1 minus frequency ratio
square we can denote this factor as the
deformation response factor which is Rd
and this is equal to this factor now
let's see how this deformation response
factor varies with the damping ratio we
have seen similar result in hand dam
systems also so in dam systems depending
upon the damping ratio the value of RT
changes so when the damping is small the
value of Rd at damping ratio is equal to
1 that's very high and when the damping
is increasing the response factor at
damping ratio 1 becomes smaller and
smaller as we have seen in the undamped
systems
the damping ratio is close to zero that
is when the forcing frequency is close
to zero we can see that our t is equal
to 1 that means the amplitude of the
steady state response will be equal to
the static response P naught by K when
the frequency ratio increases this
response factor will also increase and
that increase will depend upon the value
of damping so for light damped systems
this amplification will be larger that
frequency ratio is equal to 1 and when
the frequency ratio increases beyond 1
this factor becomes smaller and smaller
and when the frequency ratio is much
higher than 1 this becomes 0
irrespective of the damping present in
the system so the damping is controlling
this factor when the frequency ratio is
near 1 let's understand the steady-state
deformation response in little bit more
detail so the steady state response can
be written as the static response
multiplied by the deformation response
factor multiplied by sine Omega t minus
P so our D varies like this and feel
varies like this so what happens when
the frequency ratio Omega by Omega n is
much less than 1 so we have seen that
when the forcing frequency is equal to 0
or the
frequency ratio is close to zero this
factor RT is equal to one and the static
response will be equal to the dynamic
steady-state response so then the
frequency ratio is smaller than one when
it is in this range then also this Rd
value is very close to one which means
the steady-state response is
approximately equal to the static
response so in this region that is when
the frequency ratio is smaller than one
much smaller than one the response is
equal to P note by K so as you can see
from this expression this response is
controlled by the stiffness of the
system if the stiffness is high the
responses smaller the displacement will
be smaller and if the stiffness is very
low the response will be higher so this
is similar to the static case now when
the frequency ratio is near one it's
equal to or approximately equal to one
as you we have seen earlier this
amplitude of the response can be much
larger than the static response this
value of Rd can be much larger than one
the value depends upon damping for very
high value of damping like damping is
equal to 0.7 say it can happen that the
RT value is less than 1 well the
frequency ratio this one but for all
real structures the damping will be much
smaller so the are divided
you will be more than one so we can say
that when the frequency ratio is close
to one the steady-state response is
controlled by the damping in the system
so when the frequency ratio is
approximately equal to one the value of
our D would be 1 by 2 Zeta and the
steady-state amplitude becomes V naught
by K multiplied by 1 by 2 Zeta so if we
substitute the damping ratio we would
get X naught is equal to V naught by C
Omega n as you can see in these two
expressions the amplitude will be
controlled by the damping as the damping
increases the value of x naught
decreases so for small values of damping
the X naught that is the steady state
response will be much higher than the
static response so we can see the same
behavior in this curve also so now what
happens when the frequency ratio is much
larger than 1 when the frequency ratio
is larger than 1 as you can see in this
curves so the value of RT because equal
to 0 it tends to 0 as the frequency
ratio increases so this is the
expression for Rd and in this if you
observe the denominator the terms under
the rule so 1 minus frequency ratio
square the whole square so this star is
frequency ratio to the power 4 and this
term has the frequency ratio to the
power 2 so compared to
the star the value of this term is
negligible so you can say this is the
dominant term in this expression for Rd
then the frequency ratios much higher
than one so we can write the expression
for the steady-state amplitude as P
naught by K the static response
multiplied by this term that is square
root of frequency ratio to the power 4
that means Omega n square divided by
Omega square so we can substitute the
value of Omega in it as root of K by n
so this becomes P naught by M by Omega
square so as you can see here this
expression for the steady state
amplitude is controlled by the mass of
the system so when the frequency ratio
is higher than 1 Rd tends to 0 and the
value of Rd will be controlled by the
mass of the system if the mass is high
the response the steady state response
will be smaller the mass is very low
this response will be larger however as
the frequency ratio goes higher than 1
the response goes to zero it approaches
zero and this is how the phase angle
varies with damping we have noticed that
when the damping is 0 that is for
undamped system the phase angle was zero
when the damping ratio was less than 1
and it was equal to 180
when the damping ratio was higher that
one so been there is some damping
present in the system the nature of this
phase angle also changes when the
frequency ratio is close to zero
the phase angle is also close to zero
and when the frequency ratio is much
higher than 1 the phase angle approaches
180 degree and the nature of the changes
in phase angle will depend upon the
value of damping so as the damping
increases this curve becomes flatter and
it changes its values gradually so if we
want to design a structure to resist a
harmonic force
how will we design that structure what
should be its natural frequency as we
can see from these curves we know that
when the natural frequency of the system
is close to its forcing frequency the
amplitude of the steady-state response
is much higher than the static response
so we can either design the system but
the natural frequency such a way that
the frequency ratio is much less than 1
in that case our response will be simply
m/s the steady-state response or the
another way is we can design it in such
a way that the frequency ratio is much
larger than 1 so in that case the
response will be close to zero the
response will be even much lesser than
the steady-state response and in
designing a system there will also be
some
other constraints which will limit the
value of the natural frequency which we
can adopt so the general rule is that
keep the natural frequency away from the
forcing frequency as much as we can so
either make it lesser than the forcing
frequency or make it higher than the
forcing frequency now let's see the
velocity and acceleration response at
steady state so this is the displacement
response at steady state this is equal
to P naught by K Rd sine Omega t minus V
so if you differentiate this once you
will get the velocity response so the
velocity response can be written as P
naught by root K and the RV which is the
velocity distress pones factor and
multiplied by the COS function in omega
t minus V and this velocity response
factor RV this frequency ratio times Rd
so if you differentiate this you would
get this expression with our V is equal
to Omega by Omega L multiplied by RT so
if you plot this we get curves similar
to Rd it will look like this and the
values will change with the damping
ratio so this highest curve is for the
lowest damping ratio when the frequency
ratio is close to zero the value of RV
is also close to zero and when the
frequency ratio is near 1 the value of
RV increases it is much higher than 1
and its value depends upon the
and when the frequency ratio is much
higher than 1 the value of RV converges
to zero again now let's see the
steady-state acceleration response so if
we differentiate this velocity response
once we would get the acceleration
response so the acceleration response is
equal to minus P naught by M R a that is
the acceleration response factor
multiplied by sine Omega t minus V and
the acceleration response factor ra is
equal to Omega by Omega n that is the
dam frequency ratio square times R T so
if we plot this re we would get curves
similar to our V and our D and here also
when the frequency ratio is near 1 the
value of RA is much higher than 1 and
again it will depend upon the value of
the damping when the frequency ratio is
smaller than 1 the RA will have values
very close to 0 and when the frequency
ratio is much higher than 1 the value of
RA will converge to 1 so the behavior of
RA and RV away from one is different
from our D so in the case of our D then
frequency ratio was close to zero our D
was equal to 1 but RV and RA because
equals to zero when the frequency ratio
is close to zero
and when the frequency ratio is much
higher RV is equal to zero similar to
our D but re converges to 1 now let's
understand resonance in damped systems
so in undamped systems we have seen that
at resonance the response becomes
unbounded the response increases in each
cycle and that happened when the forcing
frequency is equal to the natural
frequency
so in damped systems the response will
never be unbounded so because of damping
it will be bounded so we can say that
the resonance of curse well the
responses maximum the response is
maximal when the forcing frequency is
near natural frequency it need not be
equal to natural frequency so the
resonance frequency can be defined as
the forcing frequency at which the
largest response amplitude occurs the
forcing frequency will be different for
the displacement velocity and
acceleration responses and the resonant
response will be equal to the maximum
response for displacement velocity and
acceleration and that will be when the
value of Rd RV and RA are maximum so we
can calculate the value of resonant
frequency and resonance amplitude by
maximizing the expressions for Rd RV and
RA so how will you find the maximum
value of a function we can differentiate
it with respect to the variable here in
the
case we can differentiate the
expressions for our DRV and our a with
respect to the forcing frequency and we
can equated to zero and that would
correspond to the maxima or minima and
we can find out the second derivative of
our DRV and our a and when the second
derivative is negative that indicates a
Maxima
so we can differentiate the expressions
for this and calculate the maximum value
of Rd RV and re and they are equal to
these so the maximum value of Rd is
equal to 1 by 2 Zeta square root of 1
minus Zeta Square and this happens when
the forcing frequency is a little less
than the natural frequency so the
resonant frequency for the displacement
response is Omega L multiplied by 1
minus 2 Zeta Square and for velocity
response the Maxima response factor is 1
by 2 Zeta and this happens when the
forcing frequency is equal to the
natural frequency similarly we can
calculate the resonance response for
acceleration so at resonance the
acceleration response factor would be
equal to 1 by 2 Zeta square root of 1
minus Zeta Square and this happens when
the forcing frequency is equal to Omega
L divided by square root of 1 minus 2
Zeta square so this is little higher
than Omega n so now we can see that
the resonant frequency for displacement
velocity and acceleration are slightly
different from each other
when the damping ratio is very small
these values under the square root will
become equal to one so in that case the
resonant frequency would be equal to
Omega n that is when the damping is very
very small and when the damping is very
small Rd RV and Ra all of them will be
equal to 1 by 2 Zeta because this sita
squared term will vanish then sita is
very very small now we will understand a
property of the frequency response curve
called half power bandwidth so this is
the frequency response curve for the
displacement so this is the displacement
response factor RT and it is plotted
against the frequency ratio so we know
that at resonance this curve has the
maximum value so this corresponds to the
resonant amplitude now we can find out
two frequencies on either side of this
resonant frequency where the amplitude
is equal to 1 by root 2 off the resonant
fambly tude and we can prove that the
difference between these frequencies
these frequency ratios is equal to 2
theta so that means Omega B minus Omega
I by Omega n is equal to 2 theta and
this is called half power bandwidth
because the power
system is proportional to the square of
its displacement so here these
frequencies correspond to 1 by root 2 of
the displacement amplitude so the power
is correspond to half that of the power
at resonance so this is called 1/2 power
bandwidth so if we can measure this half
power bandwidth we can calculate the
value of the damping ratio as Omega B
minus Omega I by 2 Omega n this can be
expressed in terms of the cyclic
frequencies as well so the CETA can be
expressed as FB minus FA by 2 F and
where if the response to the cyclic
frequency that is omega divided by 2 pi
to understand the dynamic properties of
structures we often test full-scale
structures using some harmonic
excitation so to do that we need to
generate harmonic forces and now we will
explore the working of a basic vibration
generator so this vibration generator
will have two masses which are of equal
mass and they are placed at some
eccentricity a from the center and these
two masses rotate in opposite directions
with some angular velocity Omega so this
will be rotating in clockwise direction
and this will be rotating in
anti-clockwise direction at time T the
eccentric masses would have moved by an
angle equal to Omega T so a force will
act on each of the eccentric masses
towards the center by the amount 1/2 ma
e omega square the horizontal component
of both of these forces will cancel out
each other and the vertical forces
remains so the vertical component will
be equivalent to Ma e Omega square sine
Omega T that is the sum of the vertical
components of both these forces so this
system will exert a harmonic force which
is equal to this much to a structure
which is attached to this vibration
generator so if we compare it with our
normal expression for the force so the P
note is equal to M e e Omega square so
this will exert a force whose amplitude
is equal to the eccentric mass times the
eccentricity times Omega square so we
can use this and find out the response
for a full-scale structure to test a
full-scale structure we can run the
vibration generator at different values
of Omega and measure the response of
that structure so from the measured
responses we can plot a curve like this
so the x axis will be the forcing
frequency for different values of Rho
forcing frequency we will have the
response of the structure so from this
we can find out the maximal response as
we have seen it earlier when the damping
is very less the resonant frequency is
equal to the natural frequency so we can
find the frequency
responding to this maximum response we
can't consider it as the natural
frequency and the damping ratio of the
structure can be calculated using the
property of half power bandwidth so we
can find out the resonant amplitude and
we can find out 1 by root 2 times the
resonant amplitude and we can calculate
FB minus FA divided by 2 FN and that
would be equal to theta so you sing
harmonic test we can calculate the
damping ratio and the natural frequency
of the structure now let's understand
the force transmitted from a vibrating
system to its support and this
information will be used in designing
the vibration isolation systems so we
have a single degree of freedom system
and it is acted by a harmonic force
equal to V naught sine Omega T so we
have to find out the force transmitted
to the support and this force will be
equal to the force in the spring plus
the force in this damper so the
transmitted force to the base is equal
to spring force plus damping force so
which is equal to K that is the
stiffness times the displacement
response plus the damping coefficient
times the velocity response so that is
equal to this value that is denote by K
multiplied by Rd that is the deformation
factor d
Meishan response factor multiplied by K
sine Omega t minus V plus C Omega cos
Omega t minus Fame
so the amplitude of this force can be
calculated as V naught by K Rd times
square root of K square plus C square
Omega square so that would be the
amplitude of the force transmitted to
the support so we can find out the ratio
of the amplitudes of the transmitted
force to the amplitude of the applied
force and that would be equal to RT
times square root of 1 plus 2 Zeta Omega
by Omega R the whole square you will get
the start from this if you divide this
by K you will get this so this ratio is
known as the transmissibility so the
transmissibility is equal to RT times
this term and we know Rd is equal to 1
by square root of 1 minus frequency
ratio square the whole square plus 2
Zeta frequency ratio the whole square so
we can write the expression for
transmissibility as this so if you plot
that relation the transmissibility
versus frequency ratio you will get
curves like this so each curve will
correspond to a different value of
damping so as in the case of deformation
response factors the highest peak at
frequency ratio is equal to 1
we'll be for the lowest damping value
when the frequency ratio is much less
than one the transmissibility is equal
to one so that means the applied force
is transmitted to the support as it is
the vibration is not at all isolated in
this case and when the frequency ratio
is close to one the transmissibility is
higher than 1 that means the transmitted
force is more than the applied force so
instead of isolating the vibration an
amplification of vibration is happening
when the frequency ratio is higher than
root 2 the transmissibility is less than
1 that means the transmitted force is
less than the applied force that means
vibration isolation is happening when
frequency ratio is Moda root 2 and the
relationship between transmissibility
and damping also changes when the
damping ratio is higher than root 2 so
when the damping ratio is close to 1 the
transmissibility was low if the damping
was high so the highest peak was
corresponding to the lowest value of
damping but after frequency ratio is
equal to root 2 this relationship
changes so beyond route to the
transmissibility is high for higher
value of damping the transmissibility is
smallest for the smallest value of
damping now let's see how ground motion
is transmitted to a structure
so we have this single degree of freedom
structure with some stiffness and
damping and it has a mass m and at the
support a ground acceleration equal to X
double dot G naught sine Omega T is
acting so this ground vibration will be
transmitted to the system and we will
find how that transmissibility is so the
effective force acting on the structure
because of this base acceleration would
be equal to minus m multiplied by this
ground acceleration so this is minus M X
double dot G naught sine Omega T and the
displacement response due to this
effective force can be found out like
this it will be minus M acceleration
amplitude divided by K Rd times sine
Omega t minus V and the acceleration of
this mass the total acceleration of this
mass will be the sum of the ground
acceleration plus the acceleration of
this mass that is the acceleration of
this mass relative to the support so the
total acceleration will be the sum of
these two so we can find the ratio of
the total acceleration of this mass to
the ground acceleration amplitude so and
that can be calculated as from this
expression it would be equal to Rd times
square root of 1 plus 2 Zeta frequency
ratio square this is similar to the
force transmissibility which we have
seen earlier
so the transmissibility here is the
ratio of the amplitude of acceleration
of this mass divided by the ground
acceleration amplitude and that would be
equal to this which is exactly same as
the force transmissibility we have seen
earlier so here also the nature of
transmissibility is similar to the force
transmissibility so we have to isolate a
structure from ground acceleration we
have to make sure that the frequency
ratio is higher there root 2 that when
the frequency ratio is higher than root
2 the transmissibility is proportional
to the damping that means if the damping
is less the transmissibility will also
be less so if you have to isolate ground
acceleration we need to have a support
but very less damping this concludes our
discussion on harmonic vibrations of is
Casilla damped systems in the next
lecture we will solve some examples
[Music]
[Music]
[Music]
