so let's see what we have done so far so
far we've been focusing on how energy
bands arise in periodic potentials I
mean what it means is when particles
move in periodic potentials how they go
in an energy band so that what it means
is energy of particles in particular we
are talking about semiconductors metals
so these particles are electrons form a
band as a function of K quantum number
which specifies the state it gives you
the wave function and at blowing zone
boundaries there are energy gaps in
these bands so there's will be one band
second band third band and so on and all
this we learnt through one
nearly free electron model and - so let
me call the previous one one-and-two
by mixing plain waves many of them and
you have mixed three of them in one of
the assignment problems and where we did
not even have the potential to be weak
so nearly free electron model works for
weak potentials and we showed how energy
gap arises an otherwise continuous
energy curve and when we mix plane waves
when a strong field we also saw how
bands arise in this lecture I'm going to
take a different perspective bands from
a different perspective and this is
important because you should be able to
see how bands arise from many many
different points of views so earlier
view was that we had a you know
electrons moving freely and then we
turned on the perturbation weak
perturbation and that gave rise to band
in a otherwise continuous energy
structure ek which was H cross square K
square over 2m in this we got a
continuous energy structure and then
there was a gap and so on so this was
the gap and then we made the potential
strong and then we mix more and more and
more plane waves and the band structure
rose now the different perspective is
going to be molecular but
effective and that brings us to mixing
of atomic orbitals so this is in
contrast to what we did in the previous
approach and that's why I kept repeating
myself or the previous approach in the
previous approach the electrons were
free and then they started interacting
through then started interacting with
this background periodic potential and
that started breaking the energy
continuous energy structure in this
atomic orbital picture we're going to
start from the atomic level that means
the electrons are going to be bound in
the electrons it's opposite of what
happened in free electron or nearly free
electron model or when we mix plane
waves brain waves means free electrons
in the molecular perspective or mixing
of atomic orbitals we are going to go
the other way and atoms have these
electrons bound to them and when we
bring them together the electrons are
going to get delocalized in the previous
case electrons were already delocalized
in this case electrons are going to be
bound in the atoms and they able to get
delocalized so let's see what we do
let's build it up let's start with a dye
atomic molecule and see what happens
there if I have two atoms
let's take homogeneous atoms they have
these energy levels let's make four of
them
and when they are brought together let's
bring them close together to form a
molecule but this is the molecule what
happens to these energy levels they come
and form molecular orbitals so I'm going
to have molecular orbitals corresponding
to each level to start with I had two
levels for each n N equals one let's say
N equals 2 N equals 3 N equals 4 and I
still have two levels for each except
that they have gotten split why do they
split their spirit because now the
potential has changed and if you recall
your chemistry the upper level is called
the anti-bonding level the lower level
is called bonding level right so let me
write it here anti-bonding and this one
is bonding for each one of these so let
me form this molecule now right and then
the levels are like this split right
empty bonding and lower one is bonding
so when I make this here is my atom here
is my atom and I have the level I'll
focus on one particular N equals one in
N equals two level and I have gotten
here the anti-bonding
orbital and here I've got the bonding
orbital these are called morning and
Auntie morning because when the molecule
is formed the bonding orbital energy has
gotten lower and the antibonding has
gotten higher now let's bring in two
more atoms their levels will also split
however they will not split as much as
the ones which are closer so they'll
probably go here let's bring in two more
atoms their levels are also split
however they'll go little low on
splitting and so on so as I bring more
and more and more atoms together I'm
going to have these levels all over
and if these let's say number of atoms
on the left is n by 2 on the right is n
by 2
I'll have n by 2 levels going up and by
2 levels going down so the picture I
have now is that I have these atoms
forming a crystal and their levels now
mix and form a continuous distribution
of energy if there are n atoms these are
n levels which I'm going to call an
energy band remember this picture now is
on the other extreme of the free
electron picture in free electron
picture already all the electrons made a
band band meetings they had continuous
energy and then when we introduced a
weak potential there appeared gaps in
that energy and each distribution before
a gap formed a band in the atomic
picture these atoms had electrons
localized on them and when we brought
them close together because of the
change in the potential the electrons
has started getting delocalized and
their levels spread and they formed a
band obviously then the next excited
state will form another band Nexus is 8
4 will form another band so this is
another way of looking at the band
picture the atomic levels mix and form
bands now what have we done here is if
you look at the molecular picture
there's two atoms right in this case the
very first approximation that one makes
is what is called as linear combination
of atomic orbitals in that the molecular
orbital sorry
molecule is written as the orbital of
atom 1 r+ orbital of atom to our let me
write coefficients a and B in front of
them and you find a and B such that the
total energy is minimized and a you know
obviously and B also related by
normalization relationship now if it is
a hormone nuclear molecule in that case
I can write a and B to be equal and
sorry molecule becomes Phi atom 1 plus
Phi atom - and another possibility
arises where I could have five atom 1
minus Phi atom - and if you recall from
your chemistry this plus sign forms the
bonding orbital and the minus sign one
forms the anti-bonding orbital
so what we have is now that we have this
diatomic molecule I have energy level up
here energy level down here and this
forms the molecular orbital equals Phi 1
minus Phi 2 and the lower one forms a
molecular orbital Phi 1 plus Phi 2 and
the levels get split in the energy can I
do similar thing in a crystal so this is
this method we call the linear
combination of atomic orbitals or in
short LC AO so the question I am asking
is should I ignore the parabola question
I'm asking now is can I do lcao for a
crystal also where many many of these
atoms are sitting can i form a linear
combination of atomic orbitals so
question is can I form a crystal orbital
that is the crystal wavefunction
for an electron right by lcao and keep
in mind one requirement would be the
wave function must satisfy
the blocks theorem and the answer to
this question is yes so if I take this
collection of atoms the wave function so
I KX that I form is equal to summation N
equals minus infinity to infinity e
raised to I K and a the atomic orbital I
am writing as Phi 80 X minus n a where
na is the position of the atom
let us take sy k X plus a to check
whether it satisfies the blocks theorem
or not so it will be N equals minus
infinity to infinity e raise to I k na
by atomic X plus a minus na which I can
write as summation N equals minus
infinity to infinity e raised to i ke na
v atomic x minus n minus 1 a which I can
further write as e raised to i ka
summation n minus 1 equals minus
infinity to plus infinity e raised to I
K n minus 1 a Phi atomic X minus n minus
1 a this summation since the summation
extends from minus infinity to plus
infinity is again psy K X and therefore
I get is equal to e raised to i ka psy K
X so I can easily write that this
satisfies
blocks theorem so I formed the
wavefunction for a particle moving in a
crystal right now I'm writing only a
one-dimensional form as summation N
equals minus infinity to infinity e
raise to I K any by atomic X minus na by
using linear combination of atomic
orbitals this is an approximate wave
function
I'm not solve the Schrodinger equation
and if I want to calculate the
corresponding energy EK it will be given
as the expectation value of the
Hamiltonian of the crystal with respect
to the psychie Hamiltonian so I K when
we calculate this expectation value with
this lcao wave function we make certain
approximations and this method is known
as the tight binding method as the name
suggests we are starting from the
extreme where the electrons were tightly
bound to each atom and become
delocalized as a result of the
Hamiltonian changing when the atoms are
brought close together and it is the
opposite end of the spectrum of where we
choose the electrons to be free to start
with and then they started forming block
waves when the weak periodic potential
was introduced
